Using the same innovation as the RB1000, the RB800 was disigned as a lighter climbing version in the MCipollini lineup. Monocoque contruction with T1000, M460J carbon fiber that is 100% hand made in the Tuscany region of Italy.
MCipollini Carbon MonoCoque
MCipollini Carbon MonoCoque The monocoque MCipollini is totally handcrafted, created with lovely attention by the designer. Small traces of this accurate realization could seem imperfections for shallow eyes. They are instead the proof of the excellence that make unique and inimitable every single MCipollini’s frame.
The Fibers used
The textiles used in the construction process are pre-impregnated with epoxy resins and are subsequently inspected to ensure that the resin content is the same on all parts. Three kinds of fibers have been used to construct the frames, all with very high performance mechanical features to guarantee uncompromised aesthetics and surfaces.
Frame construction
The cut textiles are rolled in the female mold using the following procedures: - pre-defined number of layers - automatic plotter - use of templates After rolling, vacuum treatment makes the structure compact by eliminating any air between the fibres and ensuring perfect adhesion between the layers. This process, which takes place in an autoclave with a homogeneously heated mold and pre-determinated gradient ramp pressurization, guarantees perfect product cleaning in a 210 minute cycle.
Integrated seatpost
Monocoque fork with integrated drop-out
Special headset
Our Headset is special for the two different diameters: 1”1/5 bottom - 1”1/4 top
970g
specs
RB800 GEOMETRIES
A
A1
B
a°
b°
C
D
E
F
G
XS
490
455
520
75,5°
72°
100
45
565
405
71,5
S
520
480
537
74°
73°
120
45
575
405
71,5
M
540
500
558
73,5°
73°
132
45
585
405
70
L
560
515
566
73°
73,5°
152
45
595
405
70
XL
578
534
582
73°
73,5°
170
45
605
407
68
XXL
610
563
601
72,5°
74°
193
45
620
410
68
The RB800 frame complies with the UCI regulations.
