RIDER SPECIFIC FIT & TUNE
At the foundation of performance is bike fit and geometry. If those two fundamentals are not established, all the engineering wizardry and space age materials in the world won't save your ride. You need an optimized fit and tuned geometry to give you the confidence and comfort needed to reach your performance potential.
RACE & ALL ROAD OPTIONS
The ENVE Custom Road is available with two unique personalities–Race and All Road. While identical in appearance, each has been tuned for a range of specific tire sizes and rider styles. Race prioritizes agility and responsiveness with a shorter wheelbase. All Road prioritizes stability and control with a longer wheelbase.
Frame Material ENVE M.O.D Carbon
Fork Material ENVE M.O.D Carbon
Target Application Road Race/Performance or Endurance
Sizes (cm) Custom (∼47cm, ∼50cm, ∼52cm, ∼54cm, ∼56cm, ∼58cm, ∼60cm; +/- 1cm)
Fork Rake 55, 51, 47, 43, 39 (determined during fit)
Frame Weight 850g +/- 2% (Size 56, Unpainted)
Headset ENVE Integrated IS52/IS52 Internal Drop-In
Headset Bearing 1.5″ IS52 Upper and Lower
Seat Post Diameter ENVE Integrated Seat Mast Topper
BB Type 386EVO
Brake Mount Flat Mount
Front Axle 12×100 (Total Length: 122, TP:1.5, TL:15)
Rear Axle 12×142 (Total Length: 168, TP:1.0, TL:14)
Minimum Tire Size 25c
Optimal Tire Size 27c-32c
Maximum Listed Tire Clearance 35c
Frame Routing Internal
